Specs
General Info
| Model | L20 3.0 Boost |
|---|---|
| Max Load Capacity | 150 kg (330 lbs) |
| Ride Height | 5'1" - 6'3" (155 cm - 190 cm) |
| Certification | CE (EN15194) |
| Pedal Assist | 5 Levels |
| Fold | Yes |
| Lab Tested Range | 135 km (Fully Charged) |
| Real-World Range | 120 km (PAS 1) 100 km (PAS 3) 85 km (PAS 5) |
| Waterproof Ratings | IPX7 (Waterproof Wiring) IPX6 (Display & Lights) IPX5 (Motor & Controller) IPX4 (Battery Box) |
| Terrain | Tarmac Roads & Bicycle Routes Gravel-Paved Paths Sandy Beaches & Grass Country Roads & Paved Trails |
| Bike Weight | 33.2 kg (73.2 lbs) |
| Gross Weight | Approx. 42 kg (92.6 lbs) |
Frameset
| Frame Material | 6061 Aluminum Alloy, Internal Battery, Step-Through Design |
|---|---|
| Frame Style | Compact, Full Suspension |
| Fork | Hydraulic, Adjustable Lockout, Aluminum & Iron |
| Rear Suspension | 30 mm Travel |
Wheel Set
| Tires | 20" × 3.0" Urban Hybrid Tires |
|---|---|
| Puncture Protection | 3 mm Anti-Puncture Layer |
| Wheels | 20-inch, 12-gauge Spokes, 36-hole, Double-Wall Aluminum, Black |
E-Bike System
| Motor | 48V Hub Motor |
|---|---|
| Max Torque | 75 Nm |
| Assist System | Torque Sensor |
| Battery | 48V 13.5Ah (648Wh), 21700 Cells, with BMS |
| Display | 3.5" LED Color Display, ENGWE-Designed, Mid-Position, with Bluetooth |
| ENGWE App | App Control Available |
| Charger | 54.6V 8A Output |
| Front Light | 30 Lux with Integrated E-Horn |
| Rear Light | Automatically brightens when braking or shaking |
Brakes
| Brake Type | Hydraulic, Dual-Piston |
|---|---|
| Disc Rotor | 180 mm Front & Rear |
Drivetrain
| Chain | C8R8 Anti-Rust, 116 Links |
|---|---|
| Chainring | 52T |
| Crank | 170 mm |
| Rear Derailleur | Shimano Tourney RD-TY300, 7-Speed |
| Shifter | Shimano SL-M315-7R |
| Cassette | 7-Speed, 14T–28T |
| Pedals | Boron Steel, Non-Foldable |
Cockpit
| Saddle | ENGWE Soft Saddle |
|---|---|
| Seat Post | 10-Level Adjustable |
| Handlebars | 680 mm Width |
| Stem | Foldable |
| Seat Clamp | Quick-Release |
Size
Unfolded
| Ride Height | 5'1" - 6'3" (155 cm - 190 cm) |
|---|---|
| Max Load Capacity | 150 kg (330 lbs) |
| Package Dimensions | 139 × 28 × 63 cm |
| A — Handlebar Height | 110.2 cm |
| B — Total Length | 168.0 cm |
| C — Reach | 47.2 cm |
| D — Standover Height | 38.0 cm |
| E — Wheelbase | 112.5 cm |
| F — Minimum Saddle Height | 82.0 cm |
| G — Maximum Saddle Height | 102.0 cm |
Please note: There may be a difference of 0–5 cm between measured and actual data.
Folded
| Folded Size | 100 × 51 × 75 cm |
|---|---|
| A — Height | 75 cm |
| B — Length | 100 cm |
| C — Width | 51 cm |
Please note: There may be a difference of 0–5 cm between measured and actual data.
What's in the Box?
| L20 3.0 Boost E-Bike | ×1 |
|---|---|
| Battery | 48V 13.5Ah Lithium-Ion ×1 |
| Charger | 54.6V 8A ×1 |
| Pedals | ×2 |
| Front & Rear Fenders | ×1 |
| Rear Rack | ×1 |
| Bike Kickstand | ×1 |
| Assembly Tools | ×1 |
| User Manual | ×1 |
